Medium Voltage (MV) Technical Guide: Basics for MV Design According to IEC Standards
Medium Voltage (MV) systems typically range between 1 kV and 52 kV, as defined by the International Electrotechnical Commission (IEC). The design of MV systems must comply with IEC standards, ensuring safety, reliability, and efficiency in electrical distribution networks.
1. Standards and Regulations
Key IEC Standards for MV Systems
- IEC 60038 – Standard voltages
- IEC 60298 – MV metal-enclosed switchgear
- IEC 62271 series – High-voltage switchgear and controlgear
- IEC 60076 series – Power transformers
- IEC 60502-2 – Power cables for voltages 1 kV to 36 kV
- IEC 61936-1 – Power installations exceeding 1 kV
- IEC 60840 – Cables for rated voltages above 30 kV up to 150 kV
2. MV System Components
2.1 MV Switchgear
MV switchgear is used for protection, switching, and control of electrical circuits. It can be:
- Air-insulated switchgear (AIS)
- Gas-insulated switchgear (GIS)
Switchgear Requirements (IEC 62271)
- Rated voltage (1-52 kV)
- Short-circuit current rating (e.g., 25 kA for 1 sec)
- Protection: Circuit breakers, disconnectors, earthing switches
2.2 Power Cables
MV cables must comply with IEC 60502-2 for design and installation. Key parameters include:
- Voltage rating (e.g., 6/10 kV, 12/20 kV, 18/30 kV)
- Conductor material (copper or aluminum)
- Insulation type (XLPE, EPR)
- Sheathing material (PVC, PE)
2.3 Transformers
MV transformers step down MV to LV (400V) for industrial and commercial applications.
- Standards: IEC 60076
- Types: Oil-immersed or dry-type
- Key ratings: Power rating (e.g., 1000 kVA), voltage levels, efficiency class
2.4 Protection and Control Devices
- MV Circuit Breakers (IEC 62271-100)
- Relays and Protection Systems
- Surge Arresters (IEC 60099-4) – To protect against overvoltages
3. MV Network Design Considerations
3.1 Load and Power Flow Analysis
- Determine load demand and voltage levels
- Conduct short-circuit analysis to size equipment
- Calculate power losses and efficiency
3.2 Earthing Systems (IEC 61936-1)
- TT, TN, or IT earthing configurations
- Design grounding resistance for safety
- Proper earthing of switchgear, transformers, and cables
3.3 Safety and Clearances (IEC 61936-1)
- Phase-to-phase and phase-to-ground clearances
- Minimum approach distances based on voltage level
- Fire protection for switchgear rooms and transformer areas
4. Installation and Testing
4.1 Cable Laying & Termination
- Buried cables: Depth and mechanical protection
- Overhead lines: Insulation and clearances
- Cable terminations: Stress cones, insulation coordination
4.2 Testing and Commissioning
- Dielectric tests (IEC 60243)
- Insulation resistance (Megger test)
- Partial discharge tests for GIS and cables
5. Maintenance and Reliability
- Periodic inspections of switchgear and transformers
- Thermal imaging for hotspot detection
- Circuit breaker testing (contact resistance, timing tests)
Conclusion
Designing an MV system according to IEC standards ensures safety, reliability, and efficiency. Proper selection of switchgear, cables, transformers, and protection devices is crucial for a stable power distribution system. Regular testing and maintenance further enhance system
