1. Introduction
2. What is protection relay?
2.1
Input data
Reference values...
2.3.Processes
2.4.Outputs (Results)
3.Basic objectives of protecting the power system
3.1.Reliability
3.2.Selectivity
3.3.Speed
3.4.Simplicity
3.5.Economy
4.Current transformers
4.1.Current transformers for protection
5.Overcurrent protection
5.1.Overcurrent relays
5.2.Definite(instantaneous)-current protection
5.3.Definite-time protection
5.4.Inverse-Time Protection
6.Coordination of overcurrent relays
6.1.Time-Based Coordination
6.2.Current-Based Coordination
6.3.Logic Coordination
7.Calculation task
8.Conclusion
9.References
Table of Figures
Figure 3.1.1 Electromechanical relay
Figure 3.1.2 Static relay
Figure 3.1.3 Microprocessor relay
Figure 3.1.1 Incoming and outgoing data of relay
Figure 6.2.1 Definite-current characteristic
Figure 6.3.1 Definite-time characteristic
Figure 6.4.1 Inverse-time characteristic
Figure 6.4.2 Types of inverse-time characteristics
Figure 7.1.1 Fault detection by three protection units
Figure 7.1.2 Time - delay coordination for (a) definite - time protection, (b) IDMT protection,
and (c) combined inverse - time and instantaneous protection
Figure 7.2.1 Current-based coordination. a) Line diagram; b) tripping curves
Figure 7.3.1 Logic coordination principles
List of abbreviations used
CT – current transformer
VT – voltage transformer
RTD – resistance temperature detector
RALF – rated accuracy limit factor
IOC – instantaneous overcurrent
DOC – definite time overcurrent
IDMT – inverse definite minimum time
CB – circuit breaker
Electrical overcurrent occurs when the current flowing in an electrical circuit exceeds its rated or intended capacity, leading to potential equipment damage, system outages, or even electrical fires. In power systems, overcurrent events can be caused by various factors, including short circuits, ground faults, overload conditions, and power surges.
Short circuits occur when there is a low-impedance path between two points in the circuit, causing an excessive current flow. Ground faults happen when a conductor comes in contact with the ground or another conductor that is grounded. Overload conditions occur when the electrical load exceeds the capacity of the system or equipment, causing the current to rise beyond its rated value. Power surges are brief, high-voltage transients that can result from lightning strikes, switching operations, or other disturbances.
To protect the power system and equipment from the damaging effects of overcurrent, various protective devices are employed, such as fuses, circuit breakers, relays, and surge suppressors. These devices are designed to detect and isolate overcurrent events and interrupt the current flow to prevent equipment damage and system outages.
Fuses are protective devices that contain a metal element that melts when subjected to high current, causing the circuit to open and disconnect the power supply. Circuit breakers are similar to fuses but can be reset after they have tripped. Relays are devices that monitor the current in the circuit and can trip a circuit breaker or other protective device when a fault is detected. Surge suppressors are devices that protect against power surges by diverting the excess energy to the ground.
Effective overcurrent protection is critical to maintaining the safety and reliability of the power system. It helps to prevent equipment damage, minimize system downtime, and protect people from potential hazards associated with electrical overcurrent events.
